Planar Spiral Antenna
Planar Spiral Antenna features a compact, low-profile design with wideband frequency coverage and excellent polarization characteristics. Manufactured with precision, it offers stable performance across diverse applications such as communications and radar, while customizable options ensure it meets specific customer requirements for optimized system integration.
Description
Package Information
Inquiry
| Part No | Frequency/GHz | VSWR (Max) | Gain/dB (Avg) | Axial Ratio/dB (Max) | Polarization | Interface Type |
| AO0.2G2G-PSASK | 0.2-2 | 2.50 | -2~2 | 5 | LHCP or RHCP | SMA Female |
| AO0.8G10G-PSASK | 0.8-10 | 2.50 | -2~2 | 5 | LHCP or RHCP | SMA Female |
| AO1G6G-PSASK | 1-6 | 2.50 | 1~5 | 5 | LHCP or RHCP | SMA Female |
| AO2G6G-PSASK | 2-6 | 2.50 | -2~2 | 5 | LHCP or RHCP | SMA Female |
| AO2G18G-PSASK | 2-18 | 2.50 | -1~3 | 5 | LHCP or RHCP | SMA Female |
| AO2.5G18G-PSASK | 2.5-18 | 2.50 | 3~5 | 5 | LHCP or RHCP | SMA Female |
| AO4G8G-PSASK | 4-8 | 2.50 | 2~4 | 5 | LHCP or RHCP | SMA Female |
| AO8G18G-PSASK | 8-18 | 2.50 | 1~5 | 5 | LHCP or RHCP | SMA Female |
